4110 - Nippel BSP UG / UNF IG
- Utvändig BSP-gänga med tätningskon
| Kod | Utvändig gänga R (BSP) | Invändig gänga JIC (UNF) | Förpackningsstorlek (KPL) |
|---|
| 4110-02-04 | 1/8 | 7/16-20 | 1 |
| 4110-04 | 1/4 | 7/16-20 | 1 |
| 4110-04-05 | 1/4 | 1/2-20 | 1 |
| 4110-04-06 | 1/4 | 9/16-18 | 1 |
| 4110-04-08 | 1/4 | 3/4-16 | 1 |
| 4110-06 | 3/8 | 9/16-18 | 1 |
| 4110-06-04 | 3/8 | 7/16-20 | 1 |
| 4110-06-08 | 3/8 | 3/4-16 | 1 |
| 4110-06-10 | 3/8 | 7/8-14 | 1 |
| 4110-08 | 1/2 | 3/4-16 | 1 |
| 4110-08-06 | 1/2 | 9/16-18 | 1 |
| 4110-08-10 | 1/2 | 7/8-14 | 1 |
| 4110-08-12 | 1/2 | 1 1/16-12 | 1 |
| 4110-10 | 5/8 | 7/8-14 | 1 |
| 4110-10-08 | 5/8 | 3/4-16 | 1 |
| 4110-12 | 3/4 | 1 1/16-12 | 1 |
| 4110-12-08 | 3/4 | 3/4-16 | 1 |
| 4110-12-10 | 3/4 | 7/8-14 | 1 |
| 4110-12-14 | 3/4 | 1 3/16-12 | 1 |
| 4110-12-16 | 3/4 | 1 5/16-12 | 1 |
| 4110-16 | 1 | 1 5/16-12 | 1 |
| 4110-16-12 | 1 | 1 1/16-12 | 1 |
| 4110-16-20 | 1 | 1 5/8-12 | 1 |
| 4110-20 | 1 1/4 | 1 5/8-12 | 1 |
| 4110-20-16 | 1 1/4 | 1 5/16-12 | 1 |
| 4110-20-24 | 1 1/4 | 1 7/8-12 | 1 |
| 4110-24 | 1 1/2 | 1 7/8-12 | 1 |
| 4110-32 | 2 | 2 1/2 | 1 |
